The BQ Series hydraulic tapping machine with T-slot work table/cart was suitable for use on the working range of 200mm – 1600mm, quick change safe clutch tap holder M3 – M30 to adapt your tapping work convenient & efficiently.

Feature's:-
EASY TAP BQ-22
» Tap Size : M3 - M22
» Parallel Arm
» T-Slot work Table 900x630mm, work cart
» Electric controlled device
» Optional device - 90 & various degree tapping device
» Table Mounting Column
» Hydraulic Tapping Spindle
» Choose any six safety clutch tapping adapters
» Electric motor, hydraulic pump & box

ELECTRIC SPECIFICATION

Model BQ-22
For Tap M3 – M22
Speed (rpm) 0 – 400
Work Range – Rmax(mm) 1600
Work Range – Rmin (mm) 200
Voltage 220/380 V, 50/60 HZ, 3 –Phase
Electric Motor 3 Hp
Hydraulic Pressure 100 kg/cm2
Weight (kg.) 400 / 500

EASY TAP BQ-30
» Tap Size : M4 – M30
» Parallel Arm
» T-Slot work Table 900x630mm, work cart
» Electric controlled device
» Optional device - 90 & various degree tapping device
» Table Mounting Column
» Hydraulic Tapping Spindle
» Choose any six safety clutch tapping adapters
» Electric motor, hydraulic pump & box

ELECTRIC SPECIFICATION

Model BQ-30
For Tap M4 – M30
Speed (rpm) 0-550 / 0-105
Work Range – Rmax(mm) 1600
Work Range – Rmin (mm) 200
Voltage 220/380 V, 50/60 HZ, 3 –Phase
Electric Motor 3 Hp
Hydraulic Pressure 100 kg/cm2
Weight (kg.) 400 / 500

ACCESSORIES :-

Tap Collets Adaptors

Threading Die Collets

Drill Chuck Adaptors
